CHIEFTEC zdroj SFX Smart Series, BFX-450BS, 450 W, 80+ Bronze

Name: CHIEFTEC zdroj SFX Smart Series, BFX-450BS, 450 W, 80+ Bronze
Brand: Chieftec
SKU: 1022658
Price: 1439 CZK
Availability: OutOfStock

-14%

Kód: 1022658

EAN: 753263077493

Záruka: 24 Měsíc(ů)

Výrobce: Chieftec

Do oblíbených Porovnání Dotaz prodejci Hlídání

Popis a parametry

Diskuse

CHIEFTEC zdroj SFX Smart Series, BFX-450BS, 450 W, 80+ Bronze

SMART SERIES

80 PLUS® Bronze certified efficiency
DC-to-DC technology
OCP and OTP Protection
Long Life 9cm fan

TECHNICAL SPECIFICATIONS

Model	Smart 450 W
Article no.	BFX-450BS
EAN code	0753263077493
Weight (wthout/with package)	1.03 kg / 1.5 kg
AC input	100 - 240 V / 7.0A
Frequency	47 - 63 Hz
+5V	20.0 A
+3.3 V	20.0 A
+5 V & +3.3 V combined	120 W
+12 V1	37.5 A
+12V2	-
+12V1, +12V2 combined	450 W
P.F.	>0.9
-12 V	0.3 A / 3.6 W
+ 5VBS	2.5 A / 12.5 W
Maximum Power	450 W
Connectors
20+4 PIN ATX	1
8 PIN EPS (4+4)	1
8 PIN PCIe (6+2)	2
SATA	3
MOLEX	2/1
Cable length (mm)
20+4 PIN ATX	350
8 PIN EPS (4+4)	350
8 PIN PCIe (6+2)	350 / 150
SATA	3 x 250
MOLEX / FLOPPY	2 x 150 / 150
Features
ATX12V Version	ATX 12V 2.3
Efficiency	80+ Bronze
Dimension (D x W x H)	100 x 125 x 64mm
PFC	Active PFC (0,9)
Fan	90 mm silent fan
Security	AFC (Automatic Fan speed Control) OCP (Overcurrent protection) OPP (Overload protection) OTP (Over-temperature protection) OVP (Overvoltage protection) SCP (Short-circuit protection) SIP (Surge & Inrush Protection) UVP (Under Voltage protection)
Warranty	24 Months
