Eaton 9PX 5000i RT3U Netpack, UPS 5000VA, LCD G2
General specifications
Product Name | Eaton 9PX Gen2 UPS |
Catalog Number | 9PX5KIRTNG2 |
EAN | 3553340710551 |
Product Length/Depth | 684 mm |
Product Height | 130 mm |
Product Width | 440 mm |
Product Weight | 43.1 kg |
Warranty | 3 year on electronics, 2 year on battery |
Compliances | LVD Directive (CB) EMC Directive RoHS Directive REACH WEEE Directive Packaging Directive Batteries Directive |
Certifications | IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 ENERGY STAR certified CE cULus UKCA Cm Ukr RCM |
Model Code | Eaton 9PX 5000i RT3U Netpack G2 |
Baterie
Battery type | Sealed, lead-acid |
Runtime graph | |
Battery quantity | 15 |
Battery management |
|
Battery rating | 12 V / 5 Ah |
Extended battery capability | Yes |
Výstup
Receptacle | (6) C13, (6) C39, Hardwired |
Voltage | 230V |
VA rating | 5000 VA |
Wattage | 5000W |
Output power factor | 1 |
Output voltage range | 200/208/220/230/240 V +/- 1% |
Output waveform | Sine wave |
Output nominal voltage | 230V default (200/208/220/230/240V) |
Voltage distortion output (linear load) - max | 1 |
Feed type | 1 |
Topology | Online/Double-conversion |
Vstup
Nominal frequency | 50/60 Hz |
Input power factor | >.99 |
Input voltage range | 176-276 V (100-276 V with derating) |
Input frequency range | 40-70 Hz |
Novinky a informační sdělení
Includes network card | Yes |
Communication |
|
Ethernet interface | Yes |
User interface | Multilingual graphical LCD display |
Potential free switch contact | Yes |
Expansion slots | One slot, network card included |
Software compatibility | Eaton Brlightlayer Software suite |
Type of interface | Other |
Prostředí
Altitude | 3000 m |
Noise level | <40 dB at 1 meter |
Temperature range | 0° to 40°C (32° to 104°F) |
Relative humidity | 0-95% non-condensing |
Další specifikace
Construction type | 482.6 mm (19 inch) device |
Package contents |
|
Internal bypass | Yes |
Auto shutdown function | Yes |
Color | Black/silver |
Efficiency at max. load | 96.7 |
Rack mounting kit | Yes |
Hot swap power | No |
ParametryPorovnání
Počet výstupních zásuvek
10
Použití
Data Center
Zdánlivý výkon VA
5000
Topologie
On-Line
Provedení
Tower/Rack
Fáze (Vstup/Výstup)
1:1
Komunikace
MNGMT karta
Možnosti
Prodloužení záložního času
Výška v Racku
3U
Typ výstupu
IEC 13
