MSI MB Sc LGA1151 MPG Z390 GAMING EDGE AC, Intel Z390, VGA, 4xDDR4, Wi-Fi
MPG Z390 GAMING EDGE AC
Full of sharp and salient lines reflecting gorgeous colors design, perfect balance between appearance and performance with Extended Heatsink Design, Core boost, Twin Turbo M.2, Front USB 3.1 Gen2 connector and Mystic Light
- Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
- Supports DDR4 Memory, up to 4400(OC) MHz
- Lightning Fast Game experience: 2x TURBO M.2, Intel Optane Memory Ready. Turbo USB 3.1 GEN2
- Set Core Power Free: Extended Heatsink Design, Core Boost, 8+4 pin CPU power connector, Game Boost, DDR4 Boost
- MYSTIC LIGHT: 16.8 million colors / 17 effects controlled in one click. MYSTIC LIGHT EXTENSION supports both RGB and RAINBOW LED strip.
- AUDIO BOOST 4 with NAHIMIC 3: Reward your ears with studio grade sound quality for the most immersive gaming experience
- Dragon Center: A brand new software which integrates all MSI tools like GAME MODE, VOICE BOOST, LIVE UPDATE with user friendly user interface.
TECHNICAL SPECIFICATIONS
Socket | 1151 |
CPU (max support) | i9 |
Chipset | Intel® Z390 Chipset |
DDR4 Memory | 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz |
Memory Channel | Dual |
Dimm Slots | 4 |
Max Memory (GB) | 64 |
PCI-E X16 | 3 |
PCI-E GEN | Gen3 |
PCI-E X1 | 3 |
SATAIII | 6 |
M.2 Slot | 2 |
Raid | 0/1/5/10 |
TPM (Header) | 1 |
LAN | 1x Intel® I219-V |
USB 3.1 Ports (Front) | 1(Gen2, Type C), 4(Gen1, Type A) |
USB 3.1 Ports (Rear) | 1(Gen2, Type C), 1(Gen2, Type A), 2(Gen1, Type A) |
USB 2.0 Ports (Front) | 4 |
USB 2.0 Ports (Rear) | 2 |
Serial Ports (Front) | 1 |
Audio Ports (Rear) | Realtek® ALC1220P Codec |
DisplayPort | Y |
HDMI | Y |
DirectX | 12 |
Form Factor | ATX |
SLI | Y |
Crossfire | Y |
.
ParametryPřidat do porovnání
Technologie paměti RAM
DDR4
Socket (patice)
Socket 1151
Integrovaná grafická karta
Ano
Chipset
Intel
PCI express 16x
Více než 1
Integrovaná LAN karta
1
Podpora RAID
10
Další rozhraní
M.2
Rozhraní
USB 2.0
Formát
ATX
