FRACTAL DESIGN ventilátor 140mm Venturi HP-14 PWM černý

Typ chladiče:Aktivní; Využití chladiče:Do PC skříně; Velikost ventilátoru:140x140; Barva podsvícení:bez podsvícení; Napájecí konektor:4pin.... více
Běžná cena: 759  (-18%)
511.57 Kč bez DPH
Na dotaz
619 Kč
ks
Vyberte si zvýhodněné balení
Množstevní slevy
Kód: 319655
EAN: 7350041083368
Záruka: 24 Měsíc(ů)
Výrobce: FRACTAL DESIGN
Popis a parametry
Diskuse

FRACTAL DESIGN ventilátor 140mm Venturi HP-14 PWM černý

http://www.fractal-design.com/home/product/casefans/venturi-series/venturi-hp-14-pwm

The Venturi High Pressure Series PWM fans, HP-12 and HP-14, are optimized for high-restriction airflow scenarios, making them an excellent choice for usage on large heatsinks, on radiators, or in other highly restrictive scenarios.

Designed with a variety of performance-increasing and noise-reducing features, these fans can move an amazing amount of air through restricted environments compared to other fans at the same, minimal noise level.

The HP-14 comes with two sets of solid vibration-dampening rubber corners: one for standard 140mm fan hole spacing (125mm) and one compatible with the standard 120mm hole spacing (105mm). The Venturi High Pressure Series PWM fans are ideal for those looking for a perfect balance between high performance and low noise built from sturdy, high quality materials.

Key features

  • Featuring true FDB-bearings, providing silent operation coupled with a long lifespan
  • Equipped with a counter-balanced magnet that reduces the axial tension on the bearing
  • Features integrated vibration-dampening corners, made from solid high-quality synthetic rubber
  • Dense, sturdy construction, made from high grade glass fiber reinforced thermoplastic polymer
  • Fan geometry is optimized for high pressure, delivering high performance results in high restriction usage scenarios, such as in use with large dense heatsinks or water cooling radiators.
  • Featuring PWM control with a very wide speed range, starting at only 400RPM (400 +/- 100 RPM), ideal for CPU heatsinks or radiators, where the motherboard can control the fan speed based on the CPU temperature.
  • Aerodynamically shaped thin stator struts reduce noise and unwanted turbulence.
  • Strategically placed notches on the blades further reduce and diffuse any humming noise produced when the blades pass the stator struts
  • The trip wire technology introduces a micro-turbulent layer that combats elements that negatively affect performance, resulting in quieter operation
  • Comes with a PWM Y-cable, for connecting additional fans to a single PWM header on your motherboard or PWM fan controller
  • 140mm fans come with an additional set of vibration-dampening corners are included that lends compatibility with 120mm fan mounts (105mm screw spacing). This enables the use of 140mm fans on many CPU coolers.
  • Available in 120mm and 140mm fan sizes

Specifications:

Fan

HF-12

HP-12 PWM

HF-14

HP-14 PWM

Size [mm]

120*120*25mm

120*120*25mm

140*140*25mm

140*140*25mm

Colors available

Black blades, black corners, dark grey ("Gunmetal") frame

Black blades, black corners, dark grey ("Gunmetal") frame

Black blades, black corners, dark grey ("Gunmetal") frame

Black blades, black corners, dark grey ("Gunmetal") frame

Screw hole pattern

105*105mm

105*105mm

125*125mm

105*105mm

125*125mm

105*105mm

Connector

3-pin fan header

4-pin fan header

3-pin fan header

4-pin fan header

Bearing

FDB

FDB

FDB

FDB

Number of blades

9

7

11

7

Rotational speed [RPM]

1400

1800

1200

1500

Acoustical noise [dB (A)]

25.3

31.7

26.5

30.1

Maximum air flow [CFM]

83.4

61.4

118.2

78.1

Maximum air flow [m 3 /h]

141.7

104.3

200.8

132.7

Maximum pressure [mm H 2 O]

1.22

2.3

0.95

1.94

Actual input power [W]

1.3

1.0

2.2

1.4

Maximum rated input current [A]

0.2

0.2

0.3

0.2

Nominal input voltage [V]

12V

12V

12V

12V

Minimum startup voltage [V]

4V

6V

4V

7V

Low (0-20%) PWM speed

400 RPM

400 RPM

Low PWM Static pressure

0.45 mm H2O

0.54 mm H2O

Low PWM Air flow

15.4 CFM

26.2 m3/h

24.0 CFM

40.8 m3/h

Low PWM Noise level

< 10 dB (A)

< 10 dB (A)

Low speed adapter speed

1100 RPM

850 RPM

Low speed adapter Static pressure

0.89 mm H2O

0.59 mm H2O

Low speed adapter Air flow

65.8 CFM

111.8 m3/h

78.5 CFM

133.4 m3/h

Low speed adapter Noise level

19.0 dB (A)

18.3 dB (A)

MTBF [hours]

150,000

150,000

150,000

150,000

Unit weight [g]

169

179

202

210

Package weight [g]

215

225

260

270

Cable length [mm]

500

500

500

500

Cable type

Braided all-black ribbon wire

Braided all-black ribbon wire

Braided all-black ribbon wire

Braided all-black ribbon wire

Packaging dimensions [mm]

( Including hanging tab)

180*122*30

180*122*30

200*142*30

200*142*30

Packaging dimensions [mm]

(Excluding hanging tab )

147*122*30

147*122*30

167*142*30

167*142*30

Package contents

  • Venturi Series fan
  • Screw pack with 4 metal screws
  • [HF models] Low speed adapter
  • [HP models] 1->2 PWM signal splitter cable
  • [140 mm models] 4 additional rubber corners, with 105mm hole pattern
.
ParametryPorovnání
Využití chladiče
Do PC skříně
Typ chladiče
Aktivní
Barva podsvícení
bez podsvícení
Napájecí konektor
4pin
Velikost ventilátoru
140x140
