TP-Link OMADA switch ES216G (16xGbE,fanless)

Name: TP-Link OMADA switch ES216G (16xGbE,fanless)
Brand: TP-link
SKU: 324456
Price: 2509 CZK
Availability: OutOfStock

-13%

Kód: 324456

EAN: 1210002600682

Záruka: 60 Měsíc(ů)

Výrobce: TP-link

Do oblíbených Porovnání Dotaz prodejci Hlídání

Popis a parametry

Diskuse

TP-Link OMADA switch ES216G (16xGbE,fanless)

TP-Link OMADA switch ES216G

Omada 16portový gigabitový easy managed switch

16× 10/100/1000Mb/s RJ45 portů
Snadné použití: Podporuje plug-and-play pro okamžité připojení a jednoduchou konfiguraci dalších funkcí
Centralizovaná správa cloudu prostřednictvím webu nebo aplikace Omada†
VLAN, izolace portů, test kabelů?, QoS? pro spolehlivé dohledové sítě
Automatická prevence smyček a IGMP Snooping
Konstrukce bez ventilátorů pro tichý provoz
Odolný kovový kryt a konstrukce pro montáž na stůl/rack

Stránky produktu: https://www.tp-link.com/cz/business-networking/omada-switch-agile/es216g/

Technické specifikace

HARDWARE FEATURES
Interface	• 16× 10/100/1000 Mbps RJ45 Ports • Auto-Negotiation/Auto MDI/MDIX
Fan Quantity	Fanless
Installation	• Desktop • Rackmountable
Physical Security Lock	?
Power Supply	100-240 V~50/60 Hz
Dimensions ( W x D x H )	11.6 × 5.5 × 1.7 in (294× 140 × 44 mm)
Surge Protection	±6kV
PERFORMANCE
Switching Capacity	32 Gbps
Packet Forwarding Rate	23.8 Mpps
MAC Address Table	8K
Packet Buffer Memory	4 Mbit
Jumbo Frame	15 KB
SOFTWARE FEATURES
Quality of Service	• Port-based/802.1p/DSCP QoS • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control?
L2 Features	• Static Link Aggregation • Loop Prevention / Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both • Port Statistics - Port Mirror Status - Traffic Statistics • 802.1ab LLDP
L2 Multicast	• IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave
VLAN	• MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID
Transmission Method	Store-And-Forward
Management Features
Omada App	Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management	• Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller
Cloud Access	Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning	Yes. Requires the use of Omada Cloud-Based Controller
Management Features	• Web-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery† • Batch Configuration† • Batch Firmware Upgrading† • Unified Configuration†
OTHERS
Certification	FCC, CE, RoHS
Package Content	• ES216G • Power Cord • Rubber Feet • Mounting Brackets • Screws • Installation Guide
Environment	• Operating Temperature: -5?~50? (23?~122?) • Storage Temperature: -40?~70? (-40?~158?) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing
