HPE Networking Instant On AP21 (EU) Dual Radio 2x2 Wi-Fi 6 Access Point Bundle with EU PSU S1T14A
HPE Networking Instant On AP21 (EU) Dual Radio 2x2 Wi-Fi 6 Access Point Bundle with EU PSU
HPE Networking Instant On AP21 (EU) Wi-Fi 6 Access Point Bundle with PSU (S1T14A)
The HPE Networking Instant On AP21 (S1T14A) is a compact and affordable Wi-Fi 6 (802.11ax) indoor access point bundle designed for small businesses and low-density environments. This EU bundle includes the access point, power supply unit, mounting kit, and Ethernet cable, providing a complete solution for fast deployment. It delivers reliable wireless connectivity for up to 50 devices and covers areas up to approximately 140 m2, making it ideal for offices, retail shops, and home workspaces.
Key Features
- Wi-Fi 6 (802.11ax) dual-band access point
- Supports up to 50 simultaneous client devices
- Coverage up to 1500 sq. ft. (~140 m2)
- Dual-radio 2x2 MIMO (2.4 GHz + 5 GHz)
- Smart Mesh support for wireless network extension
- Cloud-based management via Instant On mobile app or web portal
- EU bundle includes PSU, mount kit, and Ethernet cable
- Flexible powering: PoE (802.3af) or included DC adapter
- No licensing or subscription fees
Wireless Specifications
- Standards: IEEE 802.11ax (Wi-Fi 6), backward compatible with 802.11a/b/g/n/ac
- MIMO: 2x2:2 spatial streams
- Frequency bands:
- 2.4 GHz band
- 5 GHz band
- Technologies:
- OFDMA for improved efficiency and reduced latency
- MU-MIMO for simultaneous multi-client communication
- Target Wake Time (TWT) for IoT power efficiency
- Beamforming for improved signal reliability
- Aggregate throughput: up to ~1.5 Gbps
Performance and Coverage
- Optimized for low-density environments
- Supports up to 50 connected devices
- Coverage area up to 1500 sq. ft. (~140 m2)
- Ideal for conference rooms, home offices, cafés, and small businesses :contentReference[oaicite:1]{index=1}
Networking and Connectivity
- 1× Gigabit Ethernet (1 GbE Base-T uplink)
- DC power connector
- LED status indicators
- Reset / LED control button
- Kensington security slot
Security Features
- WPA3 and WPA2 support
- Enhanced Open (OWE)
- Trusted Platform Module (TPM) for secure credential storage
- Wireless access control and traffic filtering
- Guest network with captive portal support
Management
- Cloud-based management via HPE Instant On platform
- Mobile app (iOS/Android) and web portal
- Application visibility and traffic control
- Client monitoring and analytics
- Zero-touch deployment
Technical Specifications
| Parameter | Value |
|---|---|
| Product | HPE Networking Instant On AP21 (EU) |
| Part Number | S1T14A |
| Type | Indoor Access Point (Bundle) |
| Wi-Fi Standard | Wi-Fi 6 (802.11ax) |
| Radios | Dual-band 2x2 MIMO |
| Max Throughput | Up to ~1.5 Gbps |
| Max Clients | Up to 50 devices |
| Coverage | Up to 1500 sq. ft. (~140 m2) |
| Ethernet | 1× 1GbE RJ-45 uplink |
| Power | PoE (802.3af Class 3) or DC (12V) |
| Power Consumption | 10.1W (PoE) / 10.9W (DC) |
| Antenna | Integrated omni-directional 2x2 MIMO |
| Antenna Gain | 1.7 dBi (2.4 GHz), 4.8 dBi (5 GHz) |
| Max Transmit Power | Up to +21 dBm (both bands) |
| Mounting | Ceiling/Wall mount clip included |
| Warranty | 2-year warranty (24/7 phone support first 90 days) |
Package Contents
- HPE Networking Instant On AP21 Access Point
- EU Power Supply Unit (PSU)
- Ceiling and wall mount kit
- Ethernet cable
- Quick Start Guide
Additional Information
- EU regulatory domain
- Part of the HPE Instant On ecosystem for small businesses
- Supports Smart Mesh for cable-free expansion
- No recurring licensing costs
The HPE Instant On AP21 (S1T14A) bundle delivers enterprise-grade Wi-Fi 6 performance in a simple, cost-effective solution, ideal for small businesses looking for reliable, secure, and easy-to-manage wireless networking.
.ParametryPorovnání
Typ aktivního prvku
AP (Access Point)
Frekvenční pásmo (GHz)
2,4 + 5 (Dual Band)
Připojení externí antény
Ne
Podporované standardy
802.11ax
USB port
Ano
Další vlastnosti
PoE (Power over ethernet)
Další vlastnosti
Podpora 5G
Další vlastnosti
QoS (Quality of Service)
Další vlastnosti
Podpora Wi-Fi Mesh
Další vlastnosti
Rodičovská kontrola
Další vlastnosti
Firewall
Další vlastnosti
Síť pro hosty
Další vlastnosti
Print server
Další vlastnosti
Management
Další vlastnosti
FTP server
Další vlastnosti
VLAN
Slot na SIM kartu
Ano
Použití
Vnitřní
Zabezpečení
WPA3
Zabezpečení
WPA2
Typ antény
Integrovaná
Typy PoE
PoE - In
Počet WAN portů
1
Počet WAN portů
1
